Samsung 960GB SATA 6G SFF 2.5" 7mm SSD PM893 Series MZ7L3960HCJR-00W07
In-store Pickup
Local Pickup in Dallas, TX Available
- Specifications
- Description
| Manufacturer Part Number | |
| Manufacturer | |
| Condition | |
| Standard Warranty | 90 Day Replacement Warranty |
| Item Category | |
| Model | |
| Form Factor | |
| Interface | |
| External Interfaces | |
| Storage Capacity | |
| Transfer Rate | |
| Network Management Type | |
| Processor Type | |
| Clock Speed | |
| Number of Cores | |
| Cache | |
| Socket Type | |
| TDP | |
| Compatible Port | |
| Number of Ports | |
| CPU Type | |
| HDD Form Factor | |
| HDD Interface | |
| HDD Rotation Speed | |
| HDD Storage Capacity | |
| HDD Transfer Rate | |
| Memory Bus Speed | |
| Memory Capacity Per Module | |
| Memory Features | |
| Memory Form Factor | |
| Memory Kit Brand | |
| Memory Kit Breakdown | |
| Memory Kit Speed | |
| Memory Kit Technology | |
| Memory Kit Total Capacity | |
| Memory Kit Voltage | |
| Memory Number of Modules | |
| Memory Number of Pins | |
| Memory Total Capacity | |
| Memory Type | |
| Network Ports | |
| Processor Model | |
| SSD Capacity | |
| SSD Interface | |
| SSD Storage Capacity | |
| SSD Transfer Rate | |
| SSD Type |
Samsung PM893 960GB SATA III 2.5" Enterprise SSD (MZ7L3960HCJR-00W07)
Built for modern data centers, enterprise servers, and business-critical storage environments, the Samsung PM893 960GB SSD delivers an exceptional balance of performance, endurance, and reliability. Powered by Samsung's advanced V-NAND TLC technology and enterprise-grade controller architecture, this SSD is optimized for read-intensive workloads where consistent performance and data integrity are essential.
Featuring a SATA III 6Gb/s interface, high-speed sequential transfers, integrated power-loss protection, and robust hardware encryption capabilities, the PM893 is an ideal storage solution for cloud computing, virtualized environments, boot drives, content delivery systems, and enterprise applications.
Key Features
- 960GB Enterprise SSD Capacity
- SATA III 6Gb/s Interface
- Samsung PM893 Enterprise Series
- 2.5-Inch Small Form Factor
- Samsung V-NAND 3D TLC Flash
- Sequential Reads up to 550 MB/s
- Sequential Writes up to 520 MB/s
- AES 256-Bit Hardware Encryption
- Enterprise Power-Loss Protection
- 1 DWPD Enterprise Endurance Rating
Drive Specifications
- Manufacturer: Samsung
- Series: PM893
- Model Number: MZ7L3960HCJR-00W07
- Capacity: 960GB
- Controller: Samsung MKX "Metis" Enterprise Controller
- NAND Type: Samsung 3D V-NAND TLC
- Interface: SATA III 6Gb/s
- Compatibility: Backward compatible with SATA 3Gb/s and SATA 1.5Gb/s systems
- Form Factor: 2.5-Inch SFF
Performance Specifications
- Sequential Read Speed: Up to 550 MB/s
- Sequential Write Speed: Up to 520 MB/s
- Random Read Performance: Up to 98,000 IOPS
- Random Write Performance: Up to 30,000 IOPS
- Optimized for consistent enterprise workload performance
- Low-latency response for business applications and virtualization
Enterprise Endurance & Reliability
- Application Class: Read-Intensive (RI)
- Endurance: 1 Drive Write Per Day (DWPD)
- Total Bytes Written: 1,752 TBW
- MTBF: 2,000,000 Hours
- UBER: 1 Error per 1017 Bits Read
- Designed for continuous enterprise deployment
Advanced Security & Data Protection
- AES 256-Bit Hardware Encryption
- TCG Opal 2.0 Security Support
- Power-Loss Protection (PLP) with onboard tantalum capacitors
- End-to-End Data Protection
- S.M.A.R.T. Monitoring Support
- TRIM and Native Command Queuing (NCQ)
Power Efficiency
- Active Read Power: 2.1W to 2.2W
- Active Write Power: Up to 3.2W
- Idle Power Consumption: 1.3W to 1.5W
- Input Voltage: +5V (±5%)
- Energy-efficient design for dense server environments
Physical Specifications
- Form Factor: 2.5-Inch SFF
- Thickness: 7mm
- Dimensions: 100.2mm × 69.85mm × 6.8mm
- Weight: Approximately 60g
- Compatible with standard 2.5-inch SSD drive bays
Environmental Specifications
- Operating Temperature: 0°C to 70°C
- Vibration Tolerance: 20G (20-2000Hz)
- Shock Resistance: 1,500G at 0.5ms
- Engineered for enterprise operating conditions
Ideal Applications
- Enterprise Servers
- Cloud Infrastructure
- Virtualized Environments
- Web Hosting Platforms
- Boot & Operating System Drives
- Read-Intensive Databases
- Content Delivery Systems
- Data Center Storage Deployments
Why Choose the Samsung PM893 960GB SSD?
The Samsung PM893 960GB Enterprise SSD combines trusted Samsung V-NAND technology, enterprise-grade endurance, advanced security features, and reliable SATA performance into a dependable storage solution. With power-loss protection, hardware encryption, and a 1 DWPD endurance rating, it is perfectly suited for organizations seeking cost-effective, high-reliability storage for mission-critical workloads.
