Samsung 480GB SATA 6G SFF SSD PM863 Series MZ-7LM4800 MZ7LM480HCHP-000V3
In-store Pickup
Local Pickup in Dallas, TX Available
- Specifications
- Description
| Manufacturer Part Number | |
| Manufacturer | |
| Condition | |
| Standard Warranty | 90 Day Replacement Warranty |
| Item Category | |
| Model | |
| Form Factor | |
| Interface | |
| External Interfaces | |
| Storage Capacity | |
| Transfer Rate | |
| Network Management Type | |
| Processor Type | |
| Clock Speed | |
| Number of Cores | |
| Cache | |
| Socket Type | |
| TDP | |
| Compatible Port | |
| Number of Ports | |
| CPU Type | |
| HDD Form Factor | |
| HDD Interface | |
| HDD Rotation Speed | |
| HDD Storage Capacity | |
| HDD Transfer Rate | |
| Memory Bus Speed | |
| Memory Capacity Per Module | |
| Memory Features | |
| Memory Form Factor | |
| Memory Kit Brand | |
| Memory Kit Breakdown | |
| Memory Kit Speed | |
| Memory Kit Technology | |
| Memory Kit Total Capacity | |
| Memory Kit Voltage | |
| Memory Number of Modules | |
| Memory Number of Pins | |
| Memory Total Capacity | |
| Memory Type | |
| Network Ports | |
| Processor Model | |
| SSD Capacity | |
| SSD Interface | |
| SSD Storage Capacity | |
| SSD Transfer Rate | |
| SSD Type |
Samsung PM863 480GB SATA 6Gb/s 2.5" Enterprise SSD (MZ7LM480HCHP-000V3)
Built for enterprise reliability and consistent performance, the Samsung PM863 480GB SSD is a data center-class storage solution designed for read-intensive workloads. Featuring Samsung's proven 32-Layer V-NAND TLC technology, advanced data protection capabilities, and enterprise-grade endurance, the PM863 is an ideal choice for servers, storage arrays, virtualization environments, and business-critical applications.
Powered by Samsung's Mercury Controller and utilizing a SATA III 6Gb/s interface, this SSD delivers dependable performance while maintaining excellent power efficiency. The MZ7LM480HCHP-000V3 firmware version offers a standard enterprise/OEM configuration, making it suitable for deployment across a wide range of compatible platforms.
Key Features
- 480GB Enterprise Storage Capacity
- Samsung PM863 Series SSD
- 2.5-inch Small Form Factor (SFF) with 7mm height
- SATA III 6Gb/s Interface
- Samsung 32-Layer V-NAND TLC Flash Memory
- Samsung Mercury Enterprise SSD Controller
- Power-Loss Protection (PLP) for enhanced data integrity
- AES 256-Bit Hardware Encryption
- End-to-End Data Protection and advanced ECC technology
- Optimized for enterprise read-intensive workloads
Performance Specifications
- Sequential Read Speed: Up to 525 MB/s
- Sequential Write Speed: Up to 480 MB/s
- Random Read Performance (4KB): Up to 97,000 IOPS
- Random Write Performance (4KB): Up to 16,000 IOPS
- Read Latency: 120 µs
- Write Latency: 60 µs
Enterprise Reliability & Security
- Power-Loss Protection utilizes onboard tantalum capacitors to help prevent data loss during unexpected outages
- AES 256-Bit Hardware Encryption protects sensitive data at rest
- End-to-End Data Protection safeguards information across the entire data path
- Advanced ECC Engine improves data integrity and drive reliability
- 680 TBW Endurance Rating
- Up to 1.3 DWPD (Drive Writes Per Day)
- 2,000,000-Hour MTBF enterprise reliability rating
Technical Specifications
- Manufacturer: Samsung
- Series: PM863
- Model: MZ-7LM4800
- Part Number: MZ7LM480HCHP-000V3
- Capacity: 480GB
- Form Factor: 2.5-inch SFF (7mm)
- Interface: SATA III 6Gb/s (AHCI)
- NAND Type: 32-Layer Samsung V-NAND TLC
- Controller: Samsung Mercury
- Drive Class: Enterprise Read-Intensive SSD
- Encryption: AES 256-Bit Hardware Encryption
- MTBF: 2,000,000 Hours
Ideal Applications
- Enterprise Servers
- Virtualization Platforms
- Cloud Infrastructure
- Server Boot Drives
- Database and Application Servers
- Storage Arrays
- Read-Heavy Business Workloads
- 24/7 Data Center Operations
Power Efficiency
- Active Read Power: Approximately 2.4W
- Active Write Power: Approximately 3.1W
- Idle Power Consumption: Approximately 1.3W
- Operating Temperature Range: 0°C to 70°C
Why Choose the Samsung PM863?
The Samsung PM863 Series was engineered for organizations that require dependable enterprise storage without compromising reliability or efficiency. Combining enterprise-class endurance, integrated power-loss protection, advanced security features, and proven Samsung V-NAND technology, the MZ7LM480HCHP-000V3 provides a trusted storage solution for business-critical environments.
