NetAPP 10TB SAS 12G 7.2K RPM LFF 3.5" HDD SP-380A
In-store Pickup
Local Pickup in Dallas, TX Available
- Specifications
- Description
| Manufacturer Part Number | |
| Manufacturer | |
| Condition | |
| Standard Warranty | 90 Day Replacement Warranty |
| Item Category | |
| Model | |
| Form Factor | |
| Interface | |
| External Interfaces | |
| Storage Capacity | |
| Transfer Rate | |
| Network Management Type | |
| Processor Type | |
| Clock Speed | |
| Number of Cores | |
| Cache | |
| Socket Type | |
| TDP | |
| Compatible Port | |
| Number of Ports | |
| CPU Type | |
| HDD Form Factor | |
| HDD Interface | |
| HDD Rotation Speed | |
| HDD Storage Capacity | |
| HDD Transfer Rate | |
| Memory Bus Speed | |
| Memory Capacity Per Module | |
| Memory Features | |
| Memory Form Factor | |
| Memory Kit Brand | |
| Memory Kit Breakdown | |
| Memory Kit Speed | |
| Memory Kit Technology | |
| Memory Kit Total Capacity | |
| Memory Kit Voltage | |
| Memory Number of Modules | |
| Memory Number of Pins | |
| Memory Total Capacity | |
| Memory Type | |
| Network Ports | |
| Processor Model | |
| SSD Capacity | |
| SSD Interface | |
| SSD Storage Capacity | |
| SSD Transfer Rate | |
| SSD Type |
NetApp 10TB NL-SAS 12Gb/s 7.2K RPM 3.5" LFF Enterprise HDD (SP-380A / X380A-R6)
Expand your enterprise storage infrastructure with the NetApp SP-380A 10TB Nearline SAS Hard Drive, a high-capacity storage solution designed specifically for NetApp ONTAP environments. Built on the proven HGST Ultrastar enterprise platform and enhanced with NetApp-certified firmware, this drive delivers the reliability, scalability, and performance required for modern data centers, backup systems, and business-critical storage arrays.
Featuring a 10TB capacity, 12Gb/s NL-SAS interface, and 7,200 RPM spindle speed, the X380A provides an ideal balance of capacity, performance, and enterprise-grade durability for demanding workloads and large-scale storage deployments.
Key Features
- 10TB Enterprise Storage Capacity
- NetApp Service Part Number: SP-380A
- NetApp Model: X380A / X380A-R6
- NetApp Part Number: 108-00549
- 12Gb/s Nearline SAS (NL-SAS) Interface
- 3.5-inch Large Form Factor (LFF)
- 7,200 RPM Rotational Speed
- 256MB Cache Buffer
- Dual-Port SAS Connectivity for enhanced redundancy and availability
- Engineered for NetApp ONTAP storage systems
Performance Specifications
- Storage Capacity: 10TB
- Spindle Speed: 7,200 RPM
- Cache Memory: 256MB
- Interface Bandwidth: Up to 12Gb/s
- Maximum Sustained Transfer Rate: Up to 249 MB/s
- Average Latency: 4.16 ms
- Dual-port architecture for enterprise storage environments
Enterprise Reliability & Data Availability
- 24/7 Nearline Enterprise Design for continuous operation
- Dual-Port SAS Technology provides redundant data paths between storage controllers
- 2,000,000-Hour MTBF enterprise reliability rating
- Designed for mission-critical storage infrastructure
- Supports the full SCSI command set without requiring SATA tunneling or interposer hardware
- Optimized for high-density NetApp storage arrays
Technical Specifications
- Brand: NetApp
- Model: X380A / X380A-R6
- Service Part Number: SP-380A
- NetApp Part Number: 108-00549
- Base Drive Platform: HGST Ultrastar He10 / DC HC510
- Capacity: 10TB
- Form Factor: 3.5-inch LFF
- Interface: 12Gb/s NL-SAS
- Sector Format: NetApp 520-Byte Sector Format
- Cache: 256MB
- MTBF: 2,000,000 Hours
NetApp Storage Compatibility
- Minimum ONTAP Version: ONTAP 9.0 cDOT or later
- Compatible Disk Shelves: DS4246, DS212C
- Compatible FAS Systems: FAS2620, FAS2720, FAS2720A, FAS8200, FAS8300, and FAS8700 Series
- Designed specifically for NetApp enterprise storage environments
Physical Specifications
- Dimensions: 101.6mm x 147mm x 26.1mm (3.5-inch LFF)
- Enterprise-grade mechanical hard drive
- Designed for high-density storage shelves and data center deployments
Important Compatibility Notice
This drive is NetApp firmware customized and formatted using 520-byte sectors. It is intended primarily for NetApp ONTAP storage systems and compatible NetApp disk shelves. Standard servers, RAID controllers, and operating systems may not recognize or properly initialize the drive without specialized reformatting procedures and compatible hardware.
For organizations requiring dependable bulk storage, seamless NetApp integration, and enterprise-class reliability, the NetApp SP-380A 10TB NL-SAS Hard Drive delivers the performance and scalability needed for modern storage infrastructures.
