Micron 3.84TB NVMe U.2 PCIe Gen 3.0 x4 RI 2.5" SSD 9300 Pro Series MTFDHAL3T8TDP for Supermicro Server
Original price
$0.00
-
Original price
$0.00
Original price
$0.00
$1,329.99
$1,329.99
-
$1,329.99
Current price
$1,329.99
SKU MTFDHAL3T8TDP-SUPER-KIT
Availability:
50+ in stock
In-store Pickup
Local Pickup in Dallas, TX Available
- Specifications
- Description
| Manufacturer Part Number | MTFDHAL3T8TDP / MTFDHAL3T8TDP-1AT1ZABYY |
| Manufacturer | Micron |
| Condition | Refurbished |
| Standard Warranty | 90 Day Replacement Warranty |
| Item Category | Solid State Drives (SSD) |
| Model | 9300 Pro Series |
| Form Factor | SFF 2.5" SSD with Supermicro NVMe Tray |
| Interface | |
| External Interfaces | |
| Storage Capacity | |
| Transfer Rate | |
| Network Management Type | |
| Processor Type | |
| Clock Speed | |
| Number of Cores | |
| Cache | |
| Socket Type | |
| TDP | |
| Compatible Port | |
| Number of Ports | |
| CPU Type | |
| HDD Form Factor | |
| HDD Interface | |
| HDD Rotation Speed | |
| HDD Storage Capacity | |
| HDD Transfer Rate | |
| Memory Bus Speed | |
| Memory Capacity Per Module | |
| Memory Features | |
| Memory Form Factor | |
| Memory Kit Brand | |
| Memory Kit Breakdown | |
| Memory Kit Speed | |
| Memory Kit Technology | |
| Memory Kit Total Capacity | |
| Memory Kit Voltage | |
| Memory Number of Modules | |
| Memory Number of Pins | |
| Memory Total Capacity | |
| Memory Type | |
| Network Ports | |
| Processor Model | |
| SSD Capacity | |
| SSD Interface | NVMe |
| SSD Storage Capacity | 3.84 TB |
| SSD Transfer Rate | 3.84 TB |
| SSD Type |
Micron 3.84TB NVMe U.2 PCIe Gen3 x4 RI 2.5" SSD – 9300 Pro Series (with Supermicro Tray)
Part Numbers: MTFDHAL3T8TDP | MTFDHAL3T8TDP-1AT1ZABYY | MTFDHAL3T8TDP-1AT1Z
Overview
The Micron 9300 Pro 3.84TB NVMe SSD is an enterprise-grade, read‑intensive storage solution built for high-performance data center environments. Engineered to accelerate demanding workloads such as AI/ML, caching, NoSQL databases, and OLTP applications, it delivers exceptional speed, low latency, and robust data protection.
Key Features
- Enterprise-class NVMe SSD optimized for read-intensive workloads
- High capacity storage designed for cloud and hyperscale deployments
- PCIe Gen3 x4 interface for fast data throughput
- Advanced 3D TLC NAND technology for endurance and efficiency
- Built-in enterprise security and reliability features
Core Architecture
- Capacity: 3.84TB (unformatted, 1TB = 1 trillion bytes)
- Form Factor: 2.5-inch Small Form Factor (15mm thickness)
- Interface: PCIe Gen3 x4
- Protocol: NVMe 1.2
- Connector: U.2 (SFF-8639)
- NAND Flash: Micron 64-layer 3D TLC NAND
- Controller: Microchip Belmar (PM8607)
Performance (Steady State)
- Sequential Read Speed: Up to 3,500 MB/s
- Sequential Write Speed: 3,100 MB/s to 3,500 MB/s
- Random Read (4KB): Up to 850,000 IOPS
- Random Write (4KB): Up to 145,000 IOPS
-
Average Latency:
- Read: 86 µs
- Write: 11 µs
Reliability & Endurance
- Endurance Rating: 16,800 TBW
- Drive Writes Per Day: Approximately 1 DWPD (over 5 years)
- MTBF: 2,000,000 hours
- UBER: Less than 1 sector per 10¹⁷ bits read
Power & Environmental
-
Power Supply:
- 12V main supply (±8%)
- 3.3V auxiliary SMBus (±8%)
-
Power Consumption:
- Sequential Read: Up to 14W
- Sequential Write: Up to 21W
- Idle: 6.5W
- Operating Temperature: 0°C to 70°C
- Non-Operating Shock: 1000G @ 0.5ms
- Non-Operating Vibration: 3.1 GRMS (5–800Hz)
Enterprise Features
- Power Loss Protection (PLP): Protects data-in-flight and data-at-rest
- Multi-Tenancy Support: Up to 32 NVMe namespaces
- Flex Capacity: Adjustable capacity for increased endurance and performance
- Data Path Protection: End-to-end protection for user data and metadata
- Security: Digitally signed firmware and crypto erase capability
- Management: Compatible with Micron Storage Executive tools
Physical Specifications
- Height: 15.00 mm
- Width: 70.10 mm
- Length: 100.45 mm
- Weight: Less than 235 grams
Ideal Applications
- Cloud and hyperscale data centers
- Artificial intelligence and machine learning workloads
- Caching and real-time analytics systems
- NoSQL and large-scale database environments
- Enterprise storage and virtualization platforms
The Micron 9300 Pro 3.84TB NVMe SSD delivers a powerful combination of performance, endurance, and enterprise-grade features, making it a reliable choice for modern, data-intensive infrastructures.
