Kioxia 15.36TB NVMe U.3 G4 x4 RI 2.5" SED SSD KCM6FRUL15T3 for Supermicro Server
Original price
$0.00
-
Original price
$0.00
Original price
$0.00
$5,699.99
$5,699.99
-
$5,699.99
Current price
$5,699.99
SKU J6F35-SUPER-KIT
Availability:
Only 1 left!
In-store Pickup
Local Pickup in Dallas, TX Available
- Specifications
- Description
| Manufacturer Part Number | |
| Manufacturer | |
| Condition | |
| Standard Warranty | 90 Day Replacement Warranty |
| Item Category | |
| Model | |
| Form Factor | |
| Interface | |
| External Interfaces | |
| Storage Capacity | |
| Transfer Rate | |
| Network Management Type | |
| Processor Type | |
| Clock Speed | |
| Number of Cores | |
| Cache | |
| Socket Type | |
| TDP | |
| Compatible Port | |
| Number of Ports | |
| CPU Type | |
| HDD Form Factor | |
| HDD Interface | |
| HDD Rotation Speed | |
| HDD Storage Capacity | |
| HDD Transfer Rate | |
| Memory Bus Speed | |
| Memory Capacity Per Module | |
| Memory Features | |
| Memory Form Factor | |
| Memory Kit Brand | |
| Memory Kit Breakdown | |
| Memory Kit Speed | |
| Memory Kit Technology | |
| Memory Kit Total Capacity | |
| Memory Kit Voltage | |
| Memory Number of Modules | |
| Memory Number of Pins | |
| Memory Total Capacity | |
| Memory Type | |
| Network Ports | |
| Processor Model | |
| SSD Capacity | |
| SSD Interface | |
| SSD Storage Capacity | |
| SSD Transfer Rate | |
| SSD Type |
Kioxia 15.36TB NVMe U.3 PCIe Gen4 x4 SSD for Supermicro Servers
CM6-R Series | KCM6FRUL15T3
Overview
The Kioxia CM6-R 15.36TB NVMe SSD is a high-performance, enterprise-grade solid-state drive designed for read-intensive workloads in modern data centers. Built on PCIe Gen4 technology, it delivers exceptional throughput, low latency, and strong reliability, making it ideal for Supermicro server environments and mission-critical applications.
Part Numbers
- Kioxia Model: KCM6FRUL15T3
- Alternate P/N: SDFHS61DAB02T
Core Specifications
- Manufacturer: Kioxia
- Capacity: 15.36 TB
- Form Factor: 2.5" SFF (15mm)
- Interface: NVMe PCIe Gen4 x4
- Interface Type: U.3 (SFF-TA-1001)
- Backward Compatibility: Supports U.2 (SFF-8639) systems when supported by the backplane
- Flash Type: 96-layer BiCS 3D TLC NAND
Performance
- Sequential Read: Up to 6,900 MB/s
- Sequential Write: Up to 4,000 MB/s
- Random Read: Up to 1,400,000 IOPS
- Random Write: Up to 170,000 IOPS
Endurance & Reliability
- Workload Type: Read Intensive (RI)
- Endurance Rating: 1 DWPD (5 years)
- MTTF: 2.5 million hours
- Designed for continuous 24/7 enterprise operation
Security & Data Protection
- Encryption: Self-Encrypting Drive (SED)
- Compliance: FIPS 140-2 support
-
Features:
- Power Loss Protection (PLP)
- End-to-end data integrity
Physical Specifications
- Dimensions: 15.0 mm x 69.85 mm x 100.45 mm
- Weight: Up to 130g
- Power Consumption: Approx. 15W
- Operating Temperature: 0°C to 70°C
Compatibility
Supermicro Servers
Fully compatible with Supermicro systems supporting:
- NVMe U.3 or U.2 backplanes
- PCIe Gen4 NVMe infrastructure
- Hot-swap 2.5" NVMe drive bays
Commonly used in Supermicro Ultra, Hyper, and BigTwin platforms.
Cross-Platform Compatibility
Also compatible with enterprise NVMe systems from:
- Dell PowerEdge (U.2/U.3 Gen4 systems)
- HPE ProLiant Gen10 / Gen11
- Lenovo ThinkSystem servers
Important Notes
- Native U.3 SSD (next-generation standard)
- Backward compatible with U.2 systems when supported
- Not compatible with SAS or SATA controllers
- Verify backplane and controller compatibility before purchase
Summary
- Enterprise-grade Kioxia CM6-R NVMe SSD
- High-capacity 15.36TB with PCIe Gen4 performance
- Built-in encryption and advanced data protection
- Ideal for data centers, cloud, and read-heavy workloads
