Intel Xeon E5-2650 v4 2.20GHz 12-Core 30MB 105W FCLGA2011-3 Server Processor CM8066002031103 SR2N3
Product Overview
The Intel Xeon E5-2650 v4 is a powerful enterprise-class server processor based on Intel's Broadwell-EP architecture, designed for virtualization, cloud computing, database servers, high-performance computing (HPC), and mission-critical business applications. Featuring 12 cores, 24 threads, and a 30MB Intel Smart Cache, the E5-2650 v4 delivers reliable multi-threaded performance while maintaining power efficiency with a 105W TDP.
Built for the FCLGA2011-3 (Socket R3) platform, this processor supports DDR4-2400 ECC memory, Intel Hyper-Threading Technology, Intel Turbo Boost Technology 2.0, and up to 40 PCIe 3.0 lanes, making it an excellent choice for enterprise servers and professional workstations.
Key Features
- Intel Xeon E5-2650 v4 Server Processor
- Intel Part Number: CM8066002031103
- Intel Spec Code: SR2N3
- Broadwell-EP Architecture
- 12 Cores / 24 Threads
- Base Clock Speed: 2.20GHz
- Max Turbo Frequency: 2.90GHz
- 30MB Intel Smart Cache
- 105W TDP
- FCLGA2011-3 Socket
- DDR4-2400 ECC Memory Support
- Quad-Channel Memory Architecture
- Up to 40 PCIe 3.0 Lanes
- Intel Hyper-Threading Technology
- Intel Turbo Boost Technology 2.0
- Intel VT-x and VT-d Virtualization Support
- Optimized for Enterprise Servers and Workstations
- Supports Dual-Processor (2S) Server Configurations
Technical Specifications
General Specifications
- Manufacturer: Intel
- Product Family: Xeon E5 v4
- Model: E5-2650 v4
- Ordering Code: CM8066002031103
- S-Spec Number: SR2N3
- Architecture: Broadwell-EP
- Launch Date: Q1 2016
- Manufacturing Process: 14nm
- Processor Type: Server / Workstation CPU
Processor Specifications
- Core Count: 12 Cores
- Thread Count: 24 Threads
- Base Clock Speed: 2.20GHz
- Max Turbo Frequency: 2.90GHz
- L3 Cache: 30MB Intel Smart Cache
- Thermal Design Power (TDP): 105W
- Socket Type: FCLGA2011-3
- QPI Speed: 9.6 GT/s
Memory Specifications
- Memory Type: DDR4 ECC Registered / Load Reduced
- Maximum Memory Speed: DDR4-2400
- Memory Channels: 4 (Quad Channel)
- ECC Memory Support: Yes
- Maximum Memory Bandwidth: 76.8 GB/s
Expansion & Virtualization
- PCIe Version: PCIe 3.0
- PCIe Lanes: 40
- Intel Hyper-Threading Technology: Yes
- Intel Turbo Boost Technology 2.0: Yes
- Intel VT-x Virtualization: Yes
- Intel VT-d Virtualization: Yes
- Intel AES-NI: Yes
- Intel Trusted Execution Technology: Yes
- Intel 64 Architecture: Yes
Compatible Dell PowerEdge Servers
Compatible With: Dell PowerEdge R430, R530, R630, R730, R730XD, R830, R930, T430, T630, FC430, FC630, FC830, M630, C4130, C6320, and other Dell PowerEdge 13th Generation servers supporting Intel Xeon E5-2600 v4 processors.
Compatible HPE ProLiant Servers
Compatible With: HPE ProLiant DL160 Gen9, DL180 Gen9, DL360 Gen9, DL380 Gen9, DL560 Gen9, DL580 Gen9, ML350 Gen9, BL460c Gen9, and other HPE servers supporting Intel Xeon E5-2600 v4 processors.
Compatible Lenovo Servers
Compatible With: Lenovo System x3550 M5, x3650 M5, x3850 X6, x3950 X6, ThinkServer RD550, ThinkServer RD650, and other Lenovo systems supporting Intel Xeon E5-2600 v4 processors.
Compatible Supermicro Servers
Compatible With: Supermicro SYS-1028 Series, SYS-2028 Series, SYS-6028 Series, SuperServer Ultra, TwinPro, FatTwin, BigTwin, and other systems utilizing Intel C612 chipset motherboards with FCLGA2011-3 socket support.
Enterprise Applications
- Virtualization Platforms
- VMware vSphere
- Microsoft Hyper-V
- Cloud Computing
- Database Servers
- High-Performance Computing (HPC)
- Software Defined Storage (SDS)
- Enterprise Web Hosting
- Data Analytics
- Backup & Recovery Solutions
- ERP Applications
- Business-Critical Workloads
Alternate Part Numbers
- E5-2650V4
- E5-2650 v4
- CM8066002031103
- SR2N3
- BX80660E52650V4
Package Contents
- Intel Xeon E5-2650 v4 Processor
- SR2N3 FCLGA2011-3 CPU
Important Notes
- Requires an FCLGA2011-3 (Socket R3) motherboard.
- Compatible with systems supporting Intel Xeon E5-2600 v4 Series processors.
- Supports DDR4 ECC Registered and Load-Reduced memory.
- Supports single or dual-socket server configurations.
- No integrated graphics controller.
- BIOS update may be required on some systems to support v4-series Xeon processors.
The Intel Xeon E5-2650 v4 SR2N3 offers an excellent balance of core count, memory bandwidth, and power efficiency, making it ideal for virtualization hosts, enterprise servers, storage systems, and business-critical workloads requiring reliable multi-core performance.
