Intel 2TB NVMe U.2 PCIe Gen 3 x4 SFF 2.5" SED SSD DC P3520 Series 0SSDPE2MX020T7 SSDPE2MX020T7
Power your data center with the performance, reliability, and security of the Intel DC P3520 Series 2TB NVMe SSD. Engineered for enterprise storage environments, this high-capacity solid-state drive combines PCIe Gen 3 x4 NVMe technology, 3D NAND MLC flash memory, and advanced data protection features to deliver consistent performance for demanding workloads.
Designed in a 2.5-inch U.2 (SFF-8639) form factor, the DC P3520 provides significantly lower latency and higher throughput than traditional SATA-based storage solutions. With sequential read speeds of up to 1,700 MB/s and write speeds of up to 1,350 MB/s, this enterprise-class SSD accelerates data access for virtualization, cloud computing, analytics, database management, and high-performance server applications.
Built with enterprise-grade endurance and integrated security features, including AES 256-bit hardware encryption, Power Loss Protection (PLP), and end-to-end data path protection, the Intel DC P3520 helps ensure data integrity and business continuity in mission-critical environments.
Key Features
- 2TB enterprise storage capacity
- PCIe Gen 3 x4 NVMe interface
- U.2 (SFF-8639) connector
- 2.5-inch, 15mm form factor
- Enterprise-grade 3D NAND MLC flash
- Up to 1,700 MB/s sequential read
- Up to 1,350 MB/s sequential write
- Up to 375,000 random read IOPS
- Up to 26,000 random write IOPS
- Hardware-based AES 256-bit encryption
- Integrated Power Loss Protection (PLP)
- End-to-end data protection with T-10 DIF support
- Enterprise-class endurance and reliability
Technical Specifications
General Information
- Manufacturer: Intel
- Series: DC P3520
- Part Number: SSDPE2MX020T7
- Alternate Part Number: 0SSDPE2MX020T7
- Capacity: 2TB
- Form Factor: 2.5-inch
- Height: 15mm
- Interface: PCIe Gen 3 x4 NVMe
- Connector: U.2 (SFF-8639)
Performance
- Sequential Read Speed: Up to 1,700 MB/s
- Sequential Write Speed: Up to 1,350 MB/s
- Random Read Performance (4K): Up to 375,000 IOPS
- Random Write Performance (4K): Up to 26,000 IOPS
- Mixed 70/30 Read/Write Performance: Up to 85,000 IOPS
- Typical Read Latency: 20 µs
- Typical Write Latency: 20 µs
Architecture
- NAND Flash Type: 3D NAND MLC
- NVMe-enabled PCIe architecture for reduced latency and increased throughput
Security & Data Protection
- AES 256-bit Hardware Encryption
- Self-Encrypting Drive (SED) Technology
- Power Loss Protection (PLP)
- End-to-End Data Path Protection
- T-10 DIF Data Integrity Support
Reliability
- Endurance Rating: 2,490 TBW
- MTBF: 2,000,000 Hours
- Uncorrectable Bit Error Rate (UBER): Less than 1 sector per 10¹⁷ bits read
Power & Environmental Specifications
- Active Read Power: Approximately 10W
- Active Write Power: Approximately 12W
- Idle Power: Approximately 4W
- Operating Temperature: 0°C to 35°C
Ideal Applications
The Intel DC P3520 2TB NVMe SSD is purpose-built for enterprise environments requiring dependable performance and low-latency storage, including:
- Virtualized server infrastructures
- Cloud and hyperscale deployments
- Database systems
- Big data analytics
- Content delivery platforms
- High-performance computing environments
- Enterprise storage arrays
Combining high-capacity storage, NVMe speed, enterprise-class endurance, and advanced security features, the Intel DC P3520 Series SSDPE2MX020T7 is a trusted solution for organizations seeking reliable, scalable, and secure storage performance for business-critical workloads.
