HPE 15.36TB SAS 12G RI SFF 2.5" SSD Samsung PM1643a Series MZILT15THALA MZ-ILT15TB P26410-005
In-store Pickup
Local Pickup in Dallas, TX Available
- Specifications
- Description
| Manufacturer Part Number | P26410-005 / MZILT15THALA |
| Manufacturer | Samsung |
| Condition | Refurbished |
| Standard Warranty | 90 Day Replacement Warranty |
| Item Category | Solid State Drives (SSD) |
| Model | PM1643a Series MZ-ILT15TB |
| Form Factor | SFF 2.5" SSD (Tray Not Included). |
| Interface | |
| External Interfaces | |
| Storage Capacity | |
| Transfer Rate | |
| Network Management Type | |
| Processor Type | |
| Clock Speed | |
| Number of Cores | |
| Cache | |
| Socket Type | |
| TDP | |
| Compatible Port | |
| Number of Ports | |
| CPU Type | |
| HDD Form Factor | |
| HDD Interface | |
| HDD Rotation Speed | |
| HDD Storage Capacity | |
| HDD Transfer Rate | |
| Memory Bus Speed | |
| Memory Capacity Per Module | |
| Memory Features | |
| Memory Form Factor | |
| Memory Kit Brand | |
| Memory Kit Breakdown | |
| Memory Kit Speed | |
| Memory Kit Technology | |
| Memory Kit Total Capacity | |
| Memory Kit Voltage | |
| Memory Number of Modules | |
| Memory Number of Pins | |
| Memory Total Capacity | |
| Memory Type | |
| Network Ports | |
| Processor Model | |
| SSD Capacity | |
| SSD Interface | |
| SSD Storage Capacity | |
| SSD Transfer Rate | |
| SSD Type |
HPE Samsung 15.36TB SAS 12G RI SFF 2.5" SSD PM1643a Series MZILT15THALA MZ-ILT15TB P26410-005
Upgrade your enterprise storage infrastructure with the Samsung PM1643a 15.36TB SAS SSD, engineered for mission-critical data center environments that demand exceptional capacity, reliability, and consistent performance. Built with Samsung’s advanced V-NAND technology and a high-speed 12Gb/s Dual-Port SAS interface, this enterprise-class solid-state drive is ideal for virtualization, cloud computing, database applications, analytics, and other read-intensive workloads.
Designed for maximum uptime, the PM1643a delivers enterprise-grade endurance, advanced power-loss protection, and end-to-end data integrity features that help safeguard valuable business data. With a massive 15.36TB capacity in a compact 2.5-inch Small Form Factor (SFF) design, organizations can significantly increase storage density while reducing data center footprint and power consumption.
Key Features
- Massive 15.36TB Enterprise Storage Capacity
- High-Speed 12Gb/s Dual-Port SAS Interface
- Standard 2.5" SFF (15mm) Form Factor
- Optimized for Read Intensive (RI) Workloads
- Advanced Samsung 3D TLC V-NAND Technology
- Enterprise-Class Power Loss Protection
- End-to-End Data Path Protection
- Hot-Plug Compatible
- High Reliability with 2 Million Hour MTBF
- 512e Sector Format
Technical Specifications
Manufacturer: Samsung
Series: PM1643a
Model: MZ-ILT15TB
Full Model Number: MZILT15THALA
Capacity: 15.36TB
Form Factor: 2.5-inch SFF (15mm Height)
Interface: SAS 12Gb/s (Dual-Port SAS-3)
Sector Format: 512e (512-byte Emulation)
Flash Technology: Samsung 3D TLC V-NAND
Drive Type: Read Intensive (RI) Enterprise SSD
Performance
- Sequential Read Speed: Up to 2,100 MB/s
- Sequential Write Speed: Up to 1,800 MB/s
- Random Read Performance: Up to 430,000 IOPS
- Random Write Performance: Up to 70,000 IOPS
Reliability & Endurance
- Endurance Rating: 1 DWPD
- Total Endurance: Approximately 28 PBW
- MTBF: 2,000,000 Hours
- Enterprise Power Loss Protection
- End-to-End Data Protection
- Advanced ECC Error Correction
- SMART Monitoring Support
Power Consumption
- Idle Power: 5W–5.5W
- Typical Active Power: 10W–12W
- Maximum Power: 13.5W
Environmental Specifications
- Operating Temperature: 0°C to 70°C
- Storage Temperature: -40°C to 85°C
Compatible Part Numbers
- MZ-ILT15TB
- MZILT15THALA
- MZILT15THALA-00AH4
- P26410-005
- P37651-001
- 874244-007
Ideal Applications
- Enterprise Servers
- Data Centers
- Cloud Storage Platforms
- Virtualization Environments
- Database Servers
- High-Capacity Storage Arrays
- Business-Critical Read-Intensive Workloads
Package Includes
- 1 x Samsung PM1643a 15.36TB SAS 12Gb/s Enterprise SSD
Samsung PM1643a MZILT15THALA delivers the perfect combination of ultra-high capacity, enterprise reliability, and SAS performance, making it an excellent choice for organizations looking to maximize storage density while maintaining consistent mission-critical performance.
