Dell PERC H330 Mini Mono 12Gb/s SAS/SATA RAID Controller 09JXVW 9JXVW
Upgrade your Dell PowerEdge server storage performance with the Dell PERC H330 Mini Mono RAID Controller, part number 9JXVW (09JXVW). Designed for Dell 13th and select 14th Generation PowerEdge servers, this entry-level hardware RAID controller delivers reliable storage management with support for both SAS and SATA drives.
The PERC H330 utilizes a PCIe 3.0 x8 interface and provides support for up to 12Gb/s SAS and 6Gb/s SATA transfer speeds. It supports RAID 0, 1, 5, 10, and 50 configurations, enabling improved performance, data protection, and storage flexibility for enterprise environments.
Featuring Dell's Mini Mono form factor, this controller installs directly into compatible PowerEdge systems without occupying a standard PCIe expansion slot. The H330 also supports pass-through (HBA/JBOD) mode, making it suitable for software-defined storage applications and direct-drive access requirements.
Key Features
- Manufacturer: Dell
- Model: PERC H330 Mini Mono
- Dell Part Number: 9JXVW / 09JXVW
- Interface: PCIe 3.0 x8
- SAS Speed: 12Gb/s
- SATA Speed: 6Gb/s
- Form Factor: Mini Mono
- RAID Levels Supported:
- RAID 0
- RAID 1
- RAID 5
- RAID 10
- RAID 50
- Supports SAS HDDs, SATA HDDs, and SSDs
- HBA / JBOD Pass-Through Support
- Dedicated Hardware RAID Controller
- No Cache Memory Design
- Supports up to 16 Physical Drives in RAID Configurations
Compatible Dell PowerEdge Servers
- PowerEdge R430
- PowerEdge R530
- PowerEdge R630
- PowerEdge R730
- PowerEdge R730XD
- PowerEdge T430
- PowerEdge T630
- PowerEdge R640
- PowerEdge R740
- PowerEdge R7415
- Precision Rack R7910
Alternate Part Numbers
- 9JXVW
- 09JXVW
- PERC H330
- Dell PERC 9 H330 Mini Mono
Ideal For
- Dell PowerEdge Server Upgrades
- RAID Storage Configurations
- Virtualization Environments
- Business-Critical Applications
- Enterprise Storage Deployments
Before purchasing, please verify compatibility with your server model and backplane configuration. This controller is designed specifically for systems that support the Dell Mini Mono RAID controller interface and is not compatible with standard PCIe slots.
Product Condition
Tested and fully functional. Pulled from a working enterprise environment and inspected to ensure reliable operation. Ideal for replacement, upgrade, or spare inventory purposes.
