Dell Adaptec ASR-8405 12Gbps 4-Port SAS SATA Raid Controller Card 0XX5RP XX5RP
In-store Pickup
Local Pickup in Dallas, TX Available
- Specifications
- Description
| Manufacturer Part Number | 0XX5RP / XX5RP |
| Manufacturer | Dell |
| Condition | Refurbished |
| Standard Warranty | 90 Day Replacement Warranty |
| Item Category | Raid Controller Cards |
| Model | |
| Form Factor | |
| Interface | |
| External Interfaces | |
| Storage Capacity | |
| Transfer Rate | |
| Network Management Type | |
| Processor Type | |
| Clock Speed | |
| Number of Cores | |
| Cache | |
| Socket Type | |
| TDP | |
| Compatible Port | |
| Number of Ports | |
| CPU Type | |
| HDD Form Factor | |
| HDD Interface | |
| HDD Rotation Speed | |
| HDD Storage Capacity | |
| HDD Transfer Rate | |
| Memory Bus Speed | |
| Memory Capacity Per Module | |
| Memory Features | |
| Memory Form Factor | |
| Memory Kit Brand | |
| Memory Kit Breakdown | |
| Memory Kit Speed | |
| Memory Kit Technology | |
| Memory Kit Total Capacity | |
| Memory Kit Voltage | |
| Memory Number of Modules | |
| Memory Number of Pins | |
| Memory Total Capacity | |
| Memory Type | |
| Network Ports | |
| Processor Model | |
| SSD Capacity | |
| SSD Interface | |
| SSD Storage Capacity | |
| SSD Transfer Rate | |
| SSD Type |
Dell Adaptec ASR-8405 12Gb/s 4-Port SAS/SATA RAID Controller Card
Dell P/N: 0XX5RP | XX5RP
Adaptec P/N: ASR-8405 | 2277600-R
Overview
Upgrade your server storage infrastructure with the Dell Adaptec ASR-8405 RAID Controller, an enterprise-class storage solution engineered for high-performance and reliable data protection. Designed with a PCI Express 3.0 x8 host interface, the ASR-8405 delivers exceptional throughput for SAS and SATA storage environments while providing advanced RAID functionality for business-critical applications. Featuring 12Gb/s SAS connectivity, 4 internal ports, and 1GB onboard cache memory, this controller is ideal for virtualization, database management, file servers, backup appliances, and enterprise storage deployments.
The ASR-8405 supports multiple RAID levels including RAID 0, 1, 1E, 5, 6, 10, 50, and 60, allowing organizations to optimize storage performance, capacity, and redundancy according to their needs. Support for up to 256 devices through SAS expanders provides excellent scalability for growing environments, while the low-profile form factor ensures compatibility with a wide range of rackmount servers and workstation platforms.
Key Features
✔ 12Gb/s SAS and 6Gb/s SATA Support
✔ PCI Express 3.0 x8 Interface
✔ 4 Internal SAS/SATA Ports
✔ 1GB Cache Memory
✔ RAID 0, 1, 1E, 5, 6, 10, 50 & 60 Support
✔ Online Capacity Expansion
✔ RAID Migration Support
✔ Hot Spare Functionality
✔ Hot Plug Drive Support
✔ S.M.A.R.T. Monitoring
✔ Supports Up to 256 Storage Devices with SAS Expanders
✔ Low-Profile Enterprise Form Factor
Technical Specifications
Manufacturer: Dell / Adaptec
Model: ASR-8405
Dell Part Numbers: 0XX5RP, XX5RP
Manufacturer Part Number: 2277600-R
Host Interface: PCI Express 3.0 x8
Cache Memory: 1GB
Port Configuration: 4-Port Internal SAS/SATA
Connector Type: Mini SAS HD (SFF-8643)
Data Transfer Rate: Up to 12Gb/s SAS
Supported Drives: SAS and SATA HDDs & SSDs
Form Factor: Low Profile (MD2)
Supported RAID Levels: 0, 1, 1E, 5, 6, 10, 50, 60
Compatible Part Numbers
- 0XX5RP
- XX5RP
- ASR-8405
- 2277600-R
Ideal Applications
- Dell PowerEdge Servers
- Virtualization Platforms
- Enterprise Storage Systems
- Database Servers
- File Servers
- Backup & Recovery Systems
- High-Performance Workstations
Package Includes
- Dell Adaptec ASR-8405 RAID Controller Card
- Low-Profile Bracket (if included/shown)
Why Choose the Dell Adaptec ASR-8405?
The Dell Adaptec ASR-8405 combines enterprise-grade RAID protection, high-speed 12Gb/s SAS performance, and proven reliability into a compact low-profile design. With advanced RAID management features, 1GB cache memory, and support for large-scale storage deployments, this controller is an excellent choice for organizations seeking dependable storage performance and data security.
