Dell 6.4TB NVMe PCIe Gen3 x8 Mixed Use HHHL Enterprise SSD (Samsung PM1735b Series MZ-PLL6T4C / FW2K0)
Unlock enterprise-class storage performance with the Dell 6.4TB NVMe SSD FW2K0, powered by the highly regarded Samsung PM1735b Series. Designed for modern data centers, virtualization platforms, database workloads, and business-critical applications, this high-capacity SSD combines exceptional speed, advanced endurance, and enterprise-grade reliability in a compact HHHL add-in card form factor.
Leveraging a PCIe Gen3 x8 interface and the NVMe 1.2/1.3 protocol, the PM1735b delivers outstanding responsiveness with sequential read speeds up to 6,300 MB/s and random read performance reaching 980,000 IOPS. This makes it an ideal solution for organizations seeking to accelerate data-intensive workloads while maintaining consistent performance and reliability.
Key Features
- 6.4TB Enterprise Storage Capacity
- Samsung PM1735b Series Enterprise SSD
- PCIe Gen3 x8 Interface
- NVMe 1.2 / 1.3 Compliant
- Mixed Use (MU) Enterprise Workload Design
- Sequential Read Speeds up to 6,300 MB/s
- Sequential Write Speeds up to 3,300 MB/s
- Up to 980,000 Random Read IOPS
- Enterprise Power-Loss Protection
- Dell PowerEdge Platform Compatibility
Drive Specifications
- Dell Part Number: FW2K0 / 0FW2K0
- Manufacturer: Samsung
- Series: PM1735b Enterprise SSD
- Model: MZ-PLL6T4C
- Capacity: 6.4TB (6,400GB)
- NAND Technology: Samsung 3D TLC V-NAND
- Application Class: Mixed Use (MU)
- Interface: PCIe Gen3 x8
- Protocol: NVMe 1.2 / 1.3
- Form Factor: HHHL (Half-Height, Half-Length) Add-In Card
Performance Specifications
- Maximum Sequential Read: Up to 6,300 MB/s
- Maximum Sequential Write: Up to 3,300 MB/s
- Random Read Performance (4K): Up to 980,000 IOPS
- Random Write Performance (4K): Up to 190,000 IOPS
- Ultra-low latency NVMe architecture
- Optimized for transactional and mixed-use enterprise workloads
Enterprise Endurance & Reliability
- Endurance Rating: 3 DWPD (Drive Writes Per Day)
- Total Bytes Written: Up to 35,040 TBW to 58,400 TBW
- MTBF: 2,000,000 Hours
- 24/7 Enterprise Operation Ready
- Designed for long-term deployment in demanding server environments
Advanced Data Protection Features
- Power-Loss Protection (PLP) with integrated tantalum capacitors
- End-to-End Data Path Protection
- Advanced Bad Block Management
- Dynamic Thermal Throttling for workload stability
- Enhanced data integrity and operational reliability
- Protection against unexpected power interruptions
Physical Form Factor
- Form Factor: HHHL (Half-Height, Half-Length)
- Interface Requirement: PCIe x8 or x16 Physical Slot
- Suitable for rack-mounted enterprise servers
- Supports both full-height and low-profile bracket configurations
- Flexible deployment across multiple server platforms
Verified Dell PowerEdge Compatibility
- 13th Generation: PowerEdge R630, R730, R730xd, T630
- 14th Generation: PowerEdge R640, R740, R740xd, R940
- 15th Generation: PowerEdge R650, R750
- Recognized by Dell iDRAC and Lifecycle Controller management systems
Ideal Applications
- Virtualization & Hypervisor Environments
- Enterprise Databases
- Cloud Infrastructure
- High-Performance Computing (HPC)
- Software-Defined Storage
- Business Analytics Platforms
- Data Center Consolidation
- Mission-Critical Applications
Compatibility Notice
Important: This SSD utilizes a PCIe Gen3 x8 NVMe interface and requires a compatible server platform with an available PCIe x8 or x16 slot. It is specifically optimized for Dell PowerEdge server environments and enterprise infrastructure deployments.
Why Choose the Dell FW2K0 Samsung PM1735b SSD?
The Dell FW2K0 Samsung PM1735b SSD delivers an outstanding blend of enterprise performance, endurance, and reliability. With 6.4TB of high-speed NVMe storage, up to 980K IOPS, robust power-loss protection, and a 3 DWPD endurance rating, it is an ideal choice for businesses seeking to accelerate critical workloads while maintaining enterprise-grade data protection and uptime.
