Dell 6.4TB NVMe PCIe G4 x8 MU HHHL SSD Samsung PM1735 MZ-PLJ6T40 091FXC 91FXC
In-store Pickup
Local Pickup in Dallas, TX Available
- Specifications
- Description
| Manufacturer Part Number | |
| Manufacturer | |
| Condition | |
| Standard Warranty | 90 Day Replacement Warranty |
| Item Category | |
| Model | |
| Form Factor | |
| Interface | |
| External Interfaces | |
| Storage Capacity | |
| Transfer Rate | |
| Network Management Type | |
| Processor Type | |
| Clock Speed | |
| Number of Cores | |
| Cache | |
| Socket Type | |
| TDP | |
| Compatible Port | |
| Number of Ports | |
| CPU Type | |
| HDD Form Factor | |
| HDD Interface | |
| HDD Rotation Speed | |
| HDD Storage Capacity | |
| HDD Transfer Rate | |
| Memory Bus Speed | |
| Memory Capacity Per Module | |
| Memory Features | |
| Memory Form Factor | |
| Memory Kit Brand | |
| Memory Kit Breakdown | |
| Memory Kit Speed | |
| Memory Kit Technology | |
| Memory Kit Total Capacity | |
| Memory Kit Voltage | |
| Memory Number of Modules | |
| Memory Number of Pins | |
| Memory Total Capacity | |
| Memory Type | |
| Network Ports | |
| Processor Model | |
| SSD Capacity | |
| SSD Interface | |
| SSD Storage Capacity | |
| SSD Transfer Rate | |
| SSD Type |
Dell 6.4TB NVMe PCIe Gen4 x8 Mixed Use HHHL Enterprise SSD (Samsung PM1735 Series MZ-PLJ6T40 / 91FXC)
Accelerate your enterprise workloads with the Dell 6.4TB NVMe PCIe Gen4 SSD, powered by Samsung's industry-leading PM1735 Series architecture. Designed for demanding data center environments, this high-performance enterprise SSD delivers exceptional throughput, ultra-low latency, and enterprise-grade endurance for virtualization, database acceleration, analytics, cloud infrastructure, and mission-critical applications.
Featuring a PCIe Gen 4.0 x8 interface and advanced NVMe 1.4 protocol, the PM1735 delivers breakthrough performance with sequential read speeds up to 8,000 MB/s and random read performance reaching 1.5 million IOPS. The result is faster application responsiveness, reduced bottlenecks, and improved server efficiency across demanding workloads.
Key Features
- 6.4TB Enterprise NVMe Storage Capacity
- Samsung PM1735 Series Enterprise SSD
- PCIe Gen 4.0 x8 Interface
- NVMe 1.4 Protocol Support
- Mixed Use (MU) Workload Optimized
- Sequential Read Speeds up to 8,000 MB/s
- Sequential Write Speeds up to 3,800 MB/s
- Up to 1.5 Million Random Read IOPS
- Enterprise Power-Loss Protection
- Self-Encrypting Drive (SED) Support
Drive Specifications
- Dell Part Number: 91FXC / 091FXC
- Manufacturer: Samsung
- Series: PM1735 Enterprise NVMe SSD
- Model: MZ-PLJ6T40
- Capacity: 6.4TB
- NAND Technology: Samsung 3D TLC V-NAND
- Application Class: Mixed Use (MU)
- Interface: PCIe Gen 4.0 x8
- Protocol: NVMe 1.4
- Form Factor: HHHL (Half-Height, Half-Length) Add-In Card
Performance Specifications
- Maximum Sequential Read: Up to 8,000 MB/s
- Maximum Sequential Write: Up to 3,800 MB/s
- Random Read Performance (4K): Up to 1,500,000 IOPS
- Random Write Performance (4K): Up to 250,000 IOPS
- PCIe Gen4 Bandwidth for advanced enterprise workloads
- Optimized for high-throughput storage environments
Enterprise Endurance & Reliability
- Endurance Rating: 3 Drive Writes Per Day (DWPD)
- Enterprise Mixed Use Classification
- MTBF: 2,000,000 Hours
- Designed for intensive 24/7 operational workloads
- Built for long-term enterprise deployment
Advanced Data Protection
- Power-Loss Protection (PLP) using onboard tantalum capacitors
- Self-Encrypting Drive (SED) capability
- End-to-End Data Path Protection
- Advanced ECC Error Correction
- Automated Thermal Management
- Advanced Write Integrity Protection
Virtualization & Enterprise Features
- Single Root I/O Virtualization (SR-IOV) Support
- Optimized for virtual machine environments
- Ideal for software-defined storage platforms
- Supports high-density cloud and enterprise deployments
- Designed for database and analytics acceleration
Physical Form Factor
- Form Factor: HHHL (Half-Height, Half-Length)
- Interface Slot: PCIe x8 or x16 Physical Slot
- Full-height bracket typically installed
- Compatible with enterprise server PCIe expansion slots
- Designed for high-performance server environments
Verified Dell PowerEdge Compatibility
- 14th Generation: PowerEdge R640, R740, R740xd, R940
- 15th Generation: PowerEdge R650, R750, R750xa
- 16th Generation: PowerEdge R660, R760
- 17th Generation: PowerEdge R670, R770
- Recognized by Dell iDRAC and Lifecycle Controller management platforms
Ideal Applications
- Enterprise Databases
- Virtualization Clusters
- Cloud Infrastructure
- High-Performance Computing (HPC)
- Artificial Intelligence & Machine Learning
- Data Analytics Platforms
- Software-Defined Storage
- Mission-Critical Enterprise Workloads
Why Choose the Dell Samsung PM1735 6.4TB SSD?
The Dell 91FXC Samsung PM1735 delivers exceptional enterprise NVMe performance, combining 6.4TB of capacity with PCIe Gen4 bandwidth, enterprise-grade endurance, advanced security features, and industry-leading reliability. Whether you're modernizing a data center, accelerating virtualization infrastructure, or supporting high-performance applications, this SSD provides the speed, endurance, and protection that enterprise environments demand.
