Dell 3.84TB NVMe U.2 PCIe Gen 3.0 x4 MU SFF 2.5" SSD Micron 9200 Pro Series MTFDHAL3T8TCT 03FG6P 3FG6P
In-store Pickup
Local Pickup in Dallas, TX Available
- Specifications
- Description
| Manufacturer Part Number | 03FG6P / 3FG6P |
| Manufacturer | Dell / Micron |
| Condition | Refurbished |
| Standard Warranty | 90 Day Replacement Warranty |
| Item Category | |
| Model | Micron 9200 Pro Series MTFDHAL3T8TCT |
| Form Factor | SFF 2.5" SSD (Tray not Included) |
| Interface | |
| External Interfaces | |
| Storage Capacity | |
| Transfer Rate | |
| Network Management Type | |
| Processor Type | |
| Clock Speed | |
| Number of Cores | |
| Cache | |
| Socket Type | |
| TDP | |
| Compatible Port | |
| Number of Ports | |
| CPU Type | |
| HDD Form Factor | |
| HDD Interface | |
| HDD Rotation Speed | |
| HDD Storage Capacity | |
| HDD Transfer Rate | |
| Memory Bus Speed | |
| Memory Capacity Per Module | |
| Memory Features | |
| Memory Form Factor | |
| Memory Kit Brand | |
| Memory Kit Breakdown | |
| Memory Kit Speed | |
| Memory Kit Technology | |
| Memory Kit Total Capacity | |
| Memory Kit Voltage | |
| Memory Number of Modules | |
| Memory Number of Pins | |
| Memory Total Capacity | |
| Memory Type | |
| Network Ports | |
| Processor Model | |
| SSD Capacity | |
| SSD Interface | |
| SSD Storage Capacity | |
| SSD Transfer Rate | |
| SSD Type |
Dell 3.84TB NVMe U.2 PCIe Gen 3.0 x4 MU SFF 2.5" SSD Micron 9200 Pro Series MTFDHAL3T8TCT 03FG6P 3FG6P
The Dell 03FG6P (3FG6P) is a high-performance enterprise NVMe SSD based on the proven Micron 9200 Pro Series MTFDHAL3T8TCT platform. Designed for demanding data center environments, this Mixed Use (MU) SSD delivers exceptional speed, low latency, and enterprise-class reliability for virtualization, database servers, cloud computing, analytics, and high-performance storage applications.
Key Features
- Capacity: 3.84TB
- Dell Part Number: 03FG6P / 3FG6P
- Manufacturer: Micron
- Series: 9200 Pro
- Model: MTFDHAL3T8TCT
- Form Factor: 2.5" SFF (15mm)
- Interface: U.2 (SFF-8639)
- Protocol: NVMe
- PCIe Interface: PCIe Gen 3.0 x4
- NAND Flash Type: 3D TLC NAND
- Endurance Class: Mixed Use (MU)
- Sequential Read Speed: Up to 3.4 GB/s
- Sequential Write Speed: Up to 2.45 GB/s
- Random Read Performance: Up to 800,000 IOPS
- MTBF: 2 Million Hours
- Power Loss Protection (PLP)
- Hot-Plug / Hot-Swap Support
- SMART Monitoring Support
- End-to-End Data Path Protection
- Non-SED (Not a Self-Encrypting Drive)
Enterprise-Class Reliability
The Micron 9200 Pro Series is built for continuous enterprise operation and features advanced technologies that help protect your critical data. Power Loss Protection, low-latency NVMe architecture, and enterprise-grade endurance make this drive ideal for mission-critical workloads that require maximum performance and reliability.
Compatible Dell PowerEdge Servers
Compatible with Dell PowerEdge servers equipped with U.2 NVMe backplanes, including:
- PowerEdge R630 (NVMe Configurations)
- PowerEdge R730 (NVMe Configurations)
- PowerEdge R640
- PowerEdge R740
- PowerEdge R840
- PowerEdge R940
- PowerEdge R650
- PowerEdge R750
- PowerEdge R660
- PowerEdge R760
Additional Compatible Platforms
May also be compatible with systems supporting U.2 NVMe PCIe drives, including:
HPE ProLiant
- DL360 Gen9
- DL360 Gen10
- DL360 Gen10 Plus
- DL360 Gen11
- DL380 Gen9
- DL380 Gen10
- DL380 Gen10 Plus
- DL380 Gen11
- DL560 Series
- ML350 Series
Lenovo ThinkSystem
- SR630
- SR650
- SR635
- SR655
- SR850
- SR950
Cisco UCS
- C220 M5
- C220 M6
- C240 M5
- C240 M6
- C480 M5
- C480 M6
Supermicro
- SuperServer 1U Platforms
- SuperServer 2U Platforms
- SuperServer 4U Platforms
- Ultra Series
- Twin Series
- BigTwin Series
- FatTwin Series
Enterprise Workstations
- Dell Precision 5820
- Dell Precision 7820
- Dell Precision 7920
- HP Z6 Workstation
- HP Z8 Workstation
- Other systems supporting U.2 NVMe storage
Important Compatibility Notes
- Requires a U.2 NVMe-enabled backplane, bay, or adapter.
- Not compatible with SATA-only or SAS-only drive bays.
- Standard enterprise 15mm drive height.
- Compatible with many U.2 and U.3 backplanes that support NVMe drives.
Ideal Applications
- VMware, Hyper-V, and Proxmox Virtualization
- Database Servers
- Cloud Infrastructure
- Software-Defined Storage
- Artificial Intelligence (AI)
- Machine Learning
- Big Data Analytics
- High-Performance Computing (HPC)
- Enterprise Storage Arrays
- Content Delivery Platforms
- Mission-Critical Business Applications
Included
- 1x Dell 3.84TB NVMe U.2 SSD
- Dell Part Number: 03FG6P / 3FG6P
- Micron Model: MTFDHAL3T8TCT / MTFDHAL3T8TCT-1AR1ZABYY
Condition
Professionally tested, securely erased, and verified for full functionality. Enterprise-grade SSD inspected to ensure reliable operation before shipment.
