(69% Below Health) EMC 1.92TB SAS 12G RI SFF 2.5" 15mm SED SSD Toshiba PX05S Series PX05SRQ192 118033306-01
In-store Pickup
Local Pickup in Dallas, TX Available
- Specifications
- Description
| Manufacturer Part Number | 118033306-01 |
| Manufacturer | EMC / Toshiba |
| Condition | Refurbished (69% Below Health) |
| Standard Warranty | 90 Day Replacement Warranty |
| Item Category | Solid State Drives (SSD) |
| Model | PX05S Series PX05SRQ192 |
| Form Factor | SFF 2.5" SSD (Tray Not Included) |
| Interface | |
| External Interfaces | |
| Storage Capacity | |
| Transfer Rate | |
| Network Management Type | |
| Processor Type | |
| Clock Speed | |
| Number of Cores | |
| Cache | |
| Socket Type | |
| TDP | |
| Compatible Port | |
| Number of Ports | |
| CPU Type | |
| HDD Form Factor | |
| HDD Interface | |
| HDD Rotation Speed | |
| HDD Storage Capacity | |
| HDD Transfer Rate | |
| Memory Bus Speed | |
| Memory Capacity Per Module | |
| Memory Features | |
| Memory Form Factor | |
| Memory Kit Brand | |
| Memory Kit Breakdown | |
| Memory Kit Speed | |
| Memory Kit Technology | |
| Memory Kit Total Capacity | |
| Memory Kit Voltage | |
| Memory Number of Modules | |
| Memory Number of Pins | |
| Memory Total Capacity | |
| Memory Type | |
| Network Ports | |
| Processor Model | |
| SSD Capacity | |
| SSD Interface | |
| SSD Storage Capacity | |
| SSD Transfer Rate | |
| SSD Type |
EMC 1.92TB SAS 12G RI SFF 2.5" 15mm SED SSD Toshiba PX05S Series PX05SRQ192 118033306-01
Alternate Part Numbers
- 118033306-01
- PX05SRQ192
- SDFAM01EXB01
Product Overview
The EMC / Toshiba PX05SRQ192 1.92TB Enterprise SSD is a high-performance, read-intensive solid-state drive designed for mission-critical data center, enterprise storage, and server environments. Built on the proven Toshiba PX05S Series platform, this drive delivers exceptional reliability, low latency, and enterprise-class endurance while supporting dual-port SAS 12Gb/s connectivity for high-availability storage infrastructures.
Featuring 1.92TB of MLC NAND flash storage, advanced power-loss protection, self-encrypting drive (SED) security, and end-to-end data integrity protection, the PX05SRQ192 is an ideal solution for EMC storage arrays, enterprise servers, virtualization platforms, cloud computing environments, and database applications.
Key Features
- Enterprise-class 1.92TB SSD
- SAS 12Gb/s dual-port interface
- 2.5-inch SFF form factor
- 15mm drive height
- Read-Intensive (RI) workload optimized
- Self-Encrypting Drive (SED) security support
- MLC NAND flash technology
- Power Loss Protection (PLP)
- End-to-End Data Protection
- T10 DIF Data Integrity Field support
- High-availability dual-port architecture
- EMC-certified OEM enterprise storage drive
- Designed for 24x7 mission-critical operation
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Toshiba (Kioxia) |
| OEM Brand | EMC |
| Model Series | PX05S Series |
| Model Number | PX05SRQ192 |
| Part Number | 118033306-01 |
| Alternate P/N | SDFAM01EXB01, PX05SRQ192 |
| Capacity | 1.92TB |
| Form Factor | 2.5-Inch SFF |
| Drive Height | 15mm |
| Interface | SAS 12Gb/s (SAS-3) |
| Port Configuration | Dual-Port |
| Flash Technology | MLC NAND |
| Workload Type | Read Intensive (RI) |
| Encryption | Self-Encrypting Drive (SED) |
| Power Loss Protection | Yes |
| End-to-End Data Protection | Yes |
| T10 DIF Support | Yes |
| MTBF | 2,000,000 Hours |
| Endurance Rating | 1 DWPD |
| Operating Duty Cycle | 24x7 Enterprise Operation |
Performance Specifications
| Performance Metric | Rating |
|---|---|
| Sequential Read | Up to 1,800 MB/s |
| Sequential Write | Up to 850 MB/s |
| Random Read (4K) | Up to 270,000 IOPS |
| Random Write (4K) | Up to 25,000 IOPS |
| Interface Speed | 12Gb/s SAS |
Reliability and Data Protection
The Toshiba PX05SRQ192 is engineered for enterprise environments where uptime and data integrity are critical. Enterprise-grade features include:
- Advanced Power Loss Protection
- Enterprise Error Correction Technology
- End-to-End Data Path Protection
- Dual-Port Redundancy
- Self-Encrypting Security
- T10 DIF Data Integrity Verification
- 2 Million Hour MTBF Rating
- Mission-Critical 24/7 Availability
These capabilities help protect valuable business data while maintaining consistent performance under demanding workloads.
Security Features
The "Q" designation in PX05SRQ192 indicates support for Self-Encrypting Drive (SED) functionality, providing:
- Hardware-based data encryption
- Enterprise security compliance
- Secure data protection
- Reduced performance overhead compared to software encryption
Compatibility
Compatible with select EMC and enterprise server/storage environments supporting:
- SAS 12Gb/s backplanes
- 2.5-inch SFF drive bays
- EMC storage arrays
- Enterprise SAN storage systems
- Server virtualization platforms
- Cloud infrastructure deployments
Commonly deployed in:
- Dell EMC Storage Arrays
- EMC Unity Systems
- EMC VNX Platforms
- Enterprise SAS Storage Servers
- Virtualization Hosts
- Database Servers
Ideal Applications
- Enterprise Storage Arrays
- Database Servers
- Virtualization Clusters
- Cloud Computing Infrastructure
- Software-Defined Storage
- High-Availability Environments
- Read-Intensive Workloads
- Mission-Critical Applications
Package Includes
- 1x EMC Toshiba PX05SRQ192 1.92TB SAS SSD
- Part Number: 118033306-01
Why Choose the PX05SRQ192?
The Toshiba PX05SRQ192 combines enterprise-grade endurance, high-speed SAS 12Gb/s performance, advanced data protection technologies, and self-encrypting security features in a compact 2.5-inch form factor. It is an excellent choice for businesses requiring reliable, high-capacity storage for demanding data center and enterprise applications.
