NetApp 30.72TB NVMe U.2 PCIe Gen 4.0 x4 RI SFF 2.5" 15mm SED SSD Samsung BM1743 Enterprise Series MZ-WMO30T0 X4030A SP-4030A
In-store Pickup
Local Pickup in Dallas, TX Available
- Specifications
- Description
| Manufacturer Part Number | X4030A / SP-4030A |
| Manufacturer | NetAPP / Samsung |
| Condition | Refurbished |
| Standard Warranty | 90 Day Replacement Warranty |
| Item Category | Solid State Drives (SSD) |
| Model | Samsung BM1743 Enterprise Series MZ-WMO30T0 |
| Form Factor | SFF 2.5" SSD (tray Not Included) |
| Interface | |
| External Interfaces | |
| Storage Capacity | |
| Transfer Rate | |
| Network Management Type | |
| Processor Type | |
| Clock Speed | |
| Number of Cores | |
| Cache | |
| Socket Type | |
| TDP | |
| Compatible Port | |
| Number of Ports | |
| CPU Type | |
| HDD Form Factor | |
| HDD Interface | |
| HDD Rotation Speed | |
| HDD Storage Capacity | |
| HDD Transfer Rate | |
| Memory Bus Speed | |
| Memory Capacity Per Module | |
| Memory Features | |
| Memory Form Factor | |
| Memory Kit Brand | |
| Memory Kit Breakdown | |
| Memory Kit Speed | |
| Memory Kit Technology | |
| Memory Kit Total Capacity | |
| Memory Kit Voltage | |
| Memory Number of Modules | |
| Memory Number of Pins | |
| Memory Total Capacity | |
| Memory Type | |
| Network Ports | |
| Processor Model | |
| SSD Capacity | |
| SSD Interface | |
| SSD Storage Capacity | |
| SSD Transfer Rate | |
| SSD Type |
NetApp 30.72TB NVMe U.2 PCIe Gen4 x4 RI SFF 2.5" 15mm SED SSD Samsung BM1743 Series MZ-WMO30T0 X4030A SP-4030A (Tray Not Included)
Maximize storage density and performance with the NetApp X4030A / SP-4030A, powered by the enterprise-class Samsung BM1743 Series SSD. Designed for hyperscale data centers, cloud infrastructure, enterprise storage arrays, and high-performance computing environments, this drive delivers ultra-high capacity, exceptional reliability, advanced security, and outstanding NVMe performance in a compact 2.5-inch U.2 form factor.
This drive is classified as a Read Intensive (RI) SSD and includes Self-Encrypting Drive (SED) functionality with hardware-based AES-XTS 256-bit encryption and TCG Opal 2.0 compliance for enterprise-grade data security.
Key Features
- 30.72TB Enterprise NVMe SSD
- Samsung BM1743 Enterprise Series
- NetApp Certified
- Read Intensive (RI) Endurance Class
- Self-Encrypting Drive (SED)
- AES-XTS 256-bit Hardware Encryption
- TCG Opal 2.0 Compliant
- PCIe Gen4 x4 NVMe Interface
- U.2 SFF 2.5-inch Form Factor
- 15mm Height
- Enterprise Data Center Grade SSD
- Power Loss Protection (PLP)
- End-to-End Data Path Protection
- Advanced SMART Monitoring
- Optimized for Cloud, AI, HPC, and Enterprise Storage
Specifications
- Manufacturer: Samsung
- OEM Vendor: NetApp
- Series: Samsung BM1743 Enterprise
- Capacity: 30.72TB
- Model: MZ-WMO30T0
- Form Factor: 2.5" SFF U.2
- Drive Height: 15mm
- Interface: NVMe PCIe Gen4 x4
- Protocol: NVMe
- NAND Type: Samsung V-NAND
- Encryption: Self-Encrypting Drive (SED)
- Encryption Standard: AES-XTS 256-bit
- Security Compliance: TCG Opal 2.0
- Endurance Rating: 0.6 DWPD
- Sequential Read Speed: Up to 7,300 MB/s
- Sequential Write Speed: Up to 3,800 MB/s
- Random Read Performance: Up to 1,780,000 IOPS
- Random Write Performance: Up to 115,000 IOPS
- MTBF: 2.5 Million Hours
- Power Loss Protection: Yes
- End-to-End Data Protection: Yes
- Enterprise SMART Monitoring: Yes
Drive Classification
SED (Self-Encrypting Drive): Yes
This drive includes built-in hardware encryption with AES-XTS 256-bit security and TCG Opal 2.0 compliance to help protect sensitive enterprise data at rest.
RI (Read Intensive): Yes
The Samsung BM1743 is classified as a Read Intensive enterprise SSD and is optimized for workloads that require high read performance with moderate write activity, making it ideal for content delivery, cloud storage, analytics, AI inference, boot volumes, and large-scale storage systems.
Compatible Systems
Compatible with servers, storage arrays, and platforms supporting:
- U.2 NVMe Drive Bays
- PCIe Gen4 NVMe Infrastructure
- NetApp Storage Systems
- Dell PowerEdge Servers
- HPE ProLiant Servers
- Lenovo ThinkSystem Servers
- Supermicro NVMe Platforms
- Cisco UCS Servers
- Storage Appliances Supporting U.2 NVMe SSDs
Common Enterprise Applications
- NetApp Storage Arrays
- Cloud Infrastructure
- Software Defined Storage (SDS)
- AI and Machine Learning
- High Performance Computing (HPC)
- Virtualization Platforms
- VMware Environments
- Microsoft Hyper-V
- Red Hat OpenShift
- Kubernetes Clusters
- Enterprise Databases
- Big Data Analytics
- Object Storage Systems
Related Part Numbers
- MZWMO30THCLF-00AG5
- MZWMO30THCLF
- MZ-WMO30T0
- X4030A
- SP-4030A
- 108-01056+A4
Package Includes
- 1x NetApp 30.72TB NVMe SSD
- Tray Not Included
Condition
- Tested and Fully Functional
- Enterprise Grade SSD
- Cleaned and Inspected
- Tray Not Included
- No Additional Accessories Included
Please verify compatibility with your server, storage array, controller, and firmware before purchasing. This SSD requires a system that supports U.2 NVMe drives and PCIe Gen4 connectivity for optimal performance.
