Seagate 3.84TB SATA 6G RI SFF 2.5" SED SSD Nytro 1351 Series XA3840LE10063 for Supermicro Server
In-store Pickup
Local Pickup in Dallas, TX Available
- Specifications
- Description
| Manufacturer Part Number | XA3840LE10063 (with Supermicro Tray) |
| Manufacturer | Seagate |
| Condition | Refurbished |
| Standard Warranty | 90 Day Replacement Warranty |
| Item Category | Solid State Drives (SSD) |
| Model | Nytro 1351 Series |
| Form Factor | SFF 2.5" 7mm SSD (Read Description) |
| Interface | |
| External Interfaces | |
| Storage Capacity | |
| Transfer Rate | |
| Network Management Type | |
| Processor Type | |
| Clock Speed | |
| Number of Cores | |
| Cache | |
| Socket Type | |
| TDP | |
| Compatible Port | |
| Number of Ports | |
| CPU Type | |
| HDD Form Factor | |
| HDD Interface | |
| HDD Rotation Speed | |
| HDD Storage Capacity | |
| HDD Transfer Rate | |
| Memory Bus Speed | |
| Memory Capacity Per Module | |
| Memory Features | |
| Memory Form Factor | |
| Memory Kit Brand | |
| Memory Kit Breakdown | |
| Memory Kit Speed | |
| Memory Kit Technology | |
| Memory Kit Total Capacity | |
| Memory Kit Voltage | |
| Memory Number of Modules | |
| Memory Number of Pins | |
| Memory Total Capacity | |
| Memory Type | |
| Network Ports | |
| Processor Model | |
| SSD Capacity | |
| SSD Interface | |
| SSD Storage Capacity | |
| SSD Transfer Rate | |
| SSD Type |
Seagate 3.84TB SATA 6G RI SFF 2.5" SED SSD Nytro 1351 Series XA3840LE10063 for Supermicro Server
Other Related Part Number: 2LW103-001
Overview
The Seagate Nytro 1351 Series 3.84TB (XA3840LE10063) is an enterprise-grade Read Intensive (RI) Self-Encrypting Drive (SED) designed for data center and cloud environments. Built with 3D TLC NAND and a SATA 6Gb/s interface, it delivers reliable performance, strong endurance, and advanced hardware-based security.
Core Specifications
Capacity: 3.84TB (3840GB)
Interface: SATA III 6Gb/s
Form Factor: 2.5-inch SFF (7mm height)
NAND Type: 3D TLC NAND
Workload Type: Read Intensive (RI)
Endurance: 1 DWPD (~12,300 TBW over 5 years)
MTBF: 2,000,000 hours
Performance (Sustained)
Sequential Read: Up to 560 MB/s
Sequential Write: Up to 535 MB/s
Random Read (4KB): Up to 90,000 IOPS
Random Write (4KB): Up to 22,000 IOPS
Latency: ~172 µs (read) / ~58 µs (write)
Power & Physical
Power Consumption: ~3.5W active / ~1.2W idle
Dimensions: 7mm (H) x 70.1mm (W) x 100.25mm (D)
Weight: ~82g
Operating Temperature: 0°C to 70°C
Security & Enterprise Features
Encryption: AES-256 Self-Encrypting Drive (SED)
Security Standard: TCG Opal compliant
Instant Secure Erase (ISE)
Power Loss Protection
End-to-End Data Protection (SHIELD / RAISE)
DuraWrite Technology for improved endurance
Supermicro 2.5" Tray (Caddy) Compatibility
To install this 7mm SATA SSD in Supermicro systems, you must use a compatible 2.5-inch SFF hot-swap tray:
- MCP-220-00047-0B (standard Gen3 tray)
- MCP-220-00147-0B (tool-less tray)
- MCP-220-00125-0B (locking tray version)
Optional Adapter (for 3.5" bays):
- MCP-220-00043-0N (2.5" to 3.5" adapter)
Compatible Supermicro Server Platforms
This SSD is compatible with all Supermicro servers that support 2.5" SATA/SAS drive bays, including:
Ultra / Mainstream SuperServers
- SYS-1029U-TN10RT
- SYS-2029U-TR4
- SYS-6029U-TR4
- SYS-221BT-HNC0R
- SYS-5019C-M
- SYS-6019P-WTR
X11 / X12 / X13 Platform Servers
- SYS-1029 (1U platforms)
- SYS-2029 (2U platforms)
- SYS-5019 / SYS-6019 series
- X12 and X13 Hyper / Ultra systems with 2.5" bays
A+ (AMD EPYC) Systems
- AS-1114S-WN10RT
- AS-2015S-E1CR24H
High-Density Multi-Node Systems
- BigTwin: SYS-2029BT series
- FatTwin: SYS-6029TR series
Storage & SuperStorage Systems
- SSG-221P-E1CR24 (24x 2.5" bays)
- Other SSG series with hybrid SAS/SATA backplanes
Edge / Compact Servers
- SYS-111E-WR (X13 edge platform with 2.5" bays)
Compatibility Notes
- Requires SATA-compatible backplane/controller (SAS is backward compatible)
- Not supported in NVMe-only drive bays
- Fits standard 2.5" SFF 7mm bays
- Works in hybrid SAS/SATA environments
- OEM firmware is fully functional but may show as “non-certified” in some systems
Summary
The Seagate Nytro 1351 3.84TB SSD offers enterprise reliability, strong read performance, and built-in encryption. When paired with the correct Supermicro 2.5" tray, it provides seamless deployment across a wide range of Supermicro server platforms, making it an excellent choice for virtualization, cloud storage, and read-intensive workloads.
