Intel Xeon E3-1230 v5 3.40GHz Quad Core 8MB 80W FCLGA1151 CPU CM8066201921713 SR2CN SR2CN
In-store Pickup
Local Pickup in Dallas, TX Available
- Specifications
- Description
| Manufacturer Part Number | CM8066201921713 |
| Manufacturer | Intel |
| Condition | Refurbished |
| Standard Warranty | 90 Day Replacement Warranty |
| Item Category | Processors |
| Model | Intel Xeon E3-1200 v5 Series |
| Form Factor | |
| Interface | |
| External Interfaces | |
| Storage Capacity | |
| Transfer Rate | |
| Network Management Type | |
| Processor Type | |
| Clock Speed | |
| Number of Cores | 4 |
| Cache | |
| Socket Type | LGA-1151 |
| TDP | 80W |
| Compatible Port | |
| Number of Ports | |
| CPU Type | |
| HDD Form Factor | |
| HDD Interface | |
| HDD Rotation Speed | |
| HDD Storage Capacity | |
| HDD Transfer Rate | |
| Memory Bus Speed | |
| Memory Capacity Per Module | |
| Memory Features | |
| Memory Form Factor | |
| Memory Kit Brand | |
| Memory Kit Breakdown | |
| Memory Kit Speed | |
| Memory Kit Technology | |
| Memory Kit Total Capacity | |
| Memory Kit Voltage | |
| Memory Number of Modules | |
| Memory Number of Pins | |
| Memory Total Capacity | |
| Memory Type | |
| Network Ports | |
| Processor Model | |
| SSD Capacity | |
| SSD Interface | |
| SSD Storage Capacity | |
| SSD Transfer Rate | |
| SSD Type |
Intel Xeon E3-1230 v5 3.40GHz Quad-Core Server Processor (CM8066201921713 / SR2CN)
The Intel Xeon E3-1230 v5 is a dependable server and workstation processor engineered for business-critical workloads that demand stability, security, and efficient multi-threaded performance. Built on Intel's Skylake architecture, this enterprise-class CPU delivers four physical cores, eight processing threads, ECC memory support, and advanced virtualization capabilities for professional computing environments.
Featuring a 3.40GHz base frequency and Turbo Boost speeds up to 3.80GHz, the Xeon E3-1230 v5 is an excellent choice for file servers, virtualization hosts, business applications, network appliances, and entry-level workstations where reliability is a top priority.
Key Features
- Intel Xeon E3-1230 v5 Processor
- 4 Cores / 8 Threads with Intel Hyper-Threading Technology
- 3.40GHz Base Clock Speed
- Up to 3.80GHz Turbo Boost Technology 2.0
- 8MB Intel Smart Cache
- 80W Thermal Design Power (TDP)
- ECC Memory Support
- PCI Express 3.0 Support
- Enterprise-grade virtualization and security technologies
- Designed for single-socket server and workstation deployments
Processor Specifications
- Processor Family: Intel Xeon E3-1200 v5 Series
- Model: Xeon E3-1230 v5
- Ordering Code: CM8066201921713
- S-Spec: SR2CN
- Architecture: Skylake
- Manufacturing Process: 14nm
- Cores: 4
- Threads: 8
- Base Frequency: 3.40GHz
- Maximum Turbo Frequency: 3.80GHz
- Cache: 8MB Intel Smart Cache
- Bus Speed: 8 GT/s DMI3
- TDP: 80W
Memory Support
- Maximum Memory Capacity: 64GB
- Memory Types: DDR4-2133 and DDR3L-1333/1600
- Memory Channels: Dual-Channel
- Maximum Memory Bandwidth: 34.1 GB/s
- ECC Memory Support: Yes
- Enhanced reliability and data integrity for server workloads
Graphics Requirement
Important: The Intel Xeon E3-1230 v5 does not include integrated graphics. A dedicated graphics card or a server motherboard with onboard management graphics (such as an ASPEED IPMI controller) is required for video output.
Expansion & Platform Compatibility
- Socket: FCLGA1151 (Socket H4)
- Compatible Chipsets: Intel C232 and Intel C236
- PCI Express Revision: PCIe 3.0
- Maximum PCIe Lanes: 16
- Supports 1x16, 2x8, or 1x8 + 2x4 PCIe configurations
- Single-Socket (1S) Platform Support
Advanced Security & Virtualization Technologies
- Intel vPro® Technology Eligible
- Intel Software Guard Extensions (SGX)
- Intel AES-NI Hardware Encryption
- Intel Secure Key Technology
- Intel Boot Guard
- Intel Trusted Execution Technology (TXT)
- Intel VT-x Virtualization Technology
- Intel VT-d Directed I/O Virtualization
- Extended Page Tables (EPT) Support
Ideal Applications
- Business Servers
- Virtualization Hosts
- Network Attached Storage (NAS)
- File & Application Servers
- Database Systems
- Professional Workstations
- IT Infrastructure Deployments
- Enterprise Productivity Environments
Compatibility Notice
Note: The Xeon E3-1230 v5 requires an Intel C232 or C236 server/workstation motherboard. While it uses the LGA1151 socket, it is not compatible with standard consumer Intel 100-Series or 200-Series desktop motherboards such as H110, B150, H170, or Z170.
Why Choose the Intel Xeon E3-1230 v5?
Combining enterprise-class reliability, ECC memory support, Hyper-Threading technology, and robust security features, the Intel Xeon E3-1230 v5 remains a proven solution for professional server and workstation environments. Whether you're deploying virtualization workloads, business applications, or dedicated server infrastructure, this processor delivers dependable performance and long-term stability.
