(UNLOCKED) AMD EPYC 7513 2.60GHz 32 Core 128MB 200W Socket SP3 CPU 100-000000334

Compatible Part Numbers

• 100-000000334
• AMD EPYC 7513
• EPYC 7513 Milan
• AMD EPYC 7003 Series
• Socket SP3 (LGA4094)

Product Overview

The AMD EPYC 7513 is a high-performance enterprise server processor based on AMD's 3rd Generation EPYC "Milan" architecture featuring 32 cores, 64 threads, and 128MB of L3 cache. Designed for demanding virtualization, cloud, database, and high-performance computing workloads, the EPYC 7513 delivers exceptional multi-threaded performance and industry-leading I/O capabilities.

This processor is an UNLOCKED version, meaning it is not PSB (Platform Secure Boot) locked to a specific OEM vendor and can be deployed in compatible Supermicro, ASRock Rack, Gigabyte, Tyan, and other standard SP3 server platforms.

Key Features

• AMD EPYC 7513 Processor
• 32 Cores / 64 Threads
• Base Clock: 2.60GHz
• Max Boost Clock: Up to 3.65GHz
• 128MB L3 Cache
• Zen 3 Architecture
• Milan Generation (EPYC 7003 Series)
• Socket SP3 (LGA4094)
• 200W TDP
• PCIe 4.0 Support
• 128 PCIe Lanes
• 8-Channel DDR4 ECC Memory Support
• Supports Single and Dual-Socket Servers
• PSB Unlocked for Broad Compatibility

Technical Specifications

Processor Information

• Manufacturer: AMD
• Model: EPYC 7513
• Part Number: 100-000000334
• Architecture: Zen 3 (Milan)
• Process Technology: 7nm
• Processor Family: EPYC 7003 Series
• Launch Year: 2021

Performance

• CPU Cores: 32
• Threads: 64
• Base Frequency: 2.60GHz
• Max Boost Frequency: Up to 3.65GHz
• 64-Bit Processing

Cache

• L2 Cache: 16MB
• L3 Cache: 128MB
• Total Cache: 144MB

Memory Support

• DDR4 ECC RDIMM
• DDR4 ECC LRDIMM
• Maximum Memory Speed: 3200MT/s
• 8 Memory Channels
• Up to 204.8GB/s Memory Bandwidth

Expansion & I/O

• PCI Express 4.0
• 128 PCIe Lanes
• AMD Infinity Guard Security Technologies
• Secure Encrypted Virtualization (SEV)

Thermal Information

• Socket: SP3 (LGA4094)
• TDP: 200W
• Configurable TDP: 165W-200W

Equipment Compatibility

Compatible Server Platforms

The AMD EPYC 7513 is compatible with servers and motherboards supporting AMD EPYC 7003 Milan processors:

Supermicro

• Supermicro H12SSL-i
• Supermicro H12SSL-NT
• Supermicro H12DSi
• Supermicro H12DSi-NT6
• Supermicro AS-Series Servers
• Supermicro Ultra Servers

ASRock Rack

• ROMED8-2T
• ROMED8U-2L2T
• ROMED8HM3
• ROMED8-2T/BCM

Gigabyte

• MZ32-AR0
• MZ72-HB0
• R-Series EPYC Servers

Tyan

• Transport SX Platforms
• Thunder HX Series
• AMD EPYC SP3 Server Platforms

Supported Server Configurations

• Single Socket (1P)
• Dual Socket (2P)

Memory Compatibility

Supported Memory Types

• DDR4 ECC RDIMM
• DDR4 ECC LRDIMM
• 3200MT/s Memory
• 8-Channel Memory Architecture

For optimal performance, populate all eight memory channels with matching modules.

Cooling Requirements

This processor has a 200W TDP and requires an SP3-compatible server heatsink.

Compatible cooling solutions include:

• Noctua NH-U14S TR4-SP3
• Noctua NH-D9 TR4-SP3
• Supermicro SP3 Active Heatsinks
• Supermicro SP3 Passive Heatsinks (for rackmount servers)

Ideal Applications

• VMware ESXi Virtualization
• Microsoft Hyper-V
• Proxmox VE
• Nutanix Clusters
• Database Servers
• Cloud Infrastructure
• Software Defined Storage
• High Performance Computing (HPC)
• AI and Analytics Workloads
• Enterprise Data Centers

Important Note

This is an UNLOCKED (Non-PSB Locked) AMD EPYC 7513 processor. It is not restricted to a specific OEM platform and can be used in compatible AMD EPYC SP3 server motherboards with appropriate BIOS support.

Package Includes

• 1 x AMD EPYC 7513 Processor
• Part Number: 100-000000334
