Micron 1.6TB NVMe HE PCIe Gen 3.0 x4 HH-HL Add-in Card (AIC) SSD 9100 PRO MTFDHAX1T6MCE-1AN1ZABYY
In-store Pickup
Local Pickup in Dallas, TX Available
- Specifications
- Description
| Manufacturer Part Number | MTFDHAX1T6MCE-1AN1ZABYY |
| Manufacturer | Micron |
| Condition | Refurbished |
| Standard Warranty | 90 Day Replacement Warranty |
| Item Category | Solid State Drives (SSD) |
| Model | 9100 PRO Series |
| Form Factor | HH-HL Add-in Card (AIC) (Read Description) |
| Interface | |
| External Interfaces | |
| Storage Capacity | |
| Transfer Rate | |
| Network Management Type | |
| Processor Type | |
| Clock Speed | |
| Number of Cores | |
| Cache | |
| Socket Type | |
| TDP | |
| Compatible Port | |
| Number of Ports | |
| CPU Type | |
| HDD Form Factor | |
| HDD Interface | |
| HDD Rotation Speed | |
| HDD Storage Capacity | |
| HDD Transfer Rate | |
| Memory Bus Speed | |
| Memory Capacity Per Module | |
| Memory Features | |
| Memory Form Factor | |
| Memory Kit Brand | |
| Memory Kit Breakdown | |
| Memory Kit Speed | |
| Memory Kit Technology | |
| Memory Kit Total Capacity | |
| Memory Kit Voltage | |
| Memory Number of Modules | |
| Memory Number of Pins | |
| Memory Total Capacity | |
| Memory Type | |
| Network Ports | |
| Processor Model | |
| SSD Capacity | |
| SSD Interface | |
| SSD Storage Capacity | |
| SSD Transfer Rate | |
| SSD Type |
Micron 1.6TB NVMe HE PCIe Gen3 x4 HHHL AIC SSD 9100 PRO MTFDHAX1T6MCE-1AN1ZABYY
Other Related Part Number: MTFDHAX1T6MCE
Overview
The Micron 9100 PRO (MTFDHAX1T6MCE-1AN1ZABYY) is a high-endurance, enterprise-class NVMe SSD designed for read-intensive and mixed workloads. Built in a Half-Height Half-Length (HHHL) Add-In Card (AIC) form factor, it connects via PCIe Gen3 x4 and is optimized for data center environments requiring high IOPS and low latency.
Core Specifications
- Capacity: 1.6TB
- Interface: PCIe Gen3 x4 (NVMe 1.1)
- Form Factor: HHHL AIC (Add-In Card)
- NAND Type: 16nm MLC
- Sequential Read: Up to 2,800 MB/s
- Sequential Write: Up to 1,300 MB/s
- Random Read (4K): Up to 700,000 IOPS
- Random Write (4K): Up to 120,000 IOPS
- Latency: ~120µs (read) / ~30µs (write)
Endurance & Reliability
- Endurance: ~4.8PB TBW
- DWPD: ~1.6 (5 years)
- MTBF: 2.0 million hours
- Data Protection: Power-loss protection with onboard capacitors
Power & Environmental
- Idle Power: ~7W
- Typical Power: ~21W
- Max Power: Up to 30W
- Operating Temperature: 0°C to 50°C
Server Compatibility (By Manufacturer)
Dell PowerEdge Servers
16th / 17th Gen:
R660, R760, R7625
14th / 15th Gen:
R640, R740, R650, R750
13th Gen:
R530, R630, R730, T630, R930
12th Gen:
R620, R720, T620 (storage only; no native NVMe boot)
11th Gen:
R610, R710, T610 (limited support; PCIe Gen2 speeds, no boot)
HPE ProLiant Servers
Gen10 / Gen11:
DL360 Gen10/Gen11, DL380 Gen10/Gen11, ML350 Gen10
Gen9:
DL360 Gen9, DL380 Gen9 (native NVMe support and boot)
Gen8:
DL360p Gen8, DL380p Gen8 (storage only, no native boot)
Gen7 & Older:
DL360 G7, DL380 G7 (limited performance, no NVMe boot)
Supported Platforms:
DL Series (Rack), ML Series (Tower), Apollo (PCIe-enabled nodes)
Supermicro Servers / Motherboards
X11 / X12 / X13 Series:
X11DPi, X12SPW, X13SEW (full NVMe + UEFI boot support)
X10 Series:
X10DRi, X10SRL, X10SDV (boot supported with updated BIOS)
X9 Series:
X9DR3, X9SCM (storage only, no native NVMe boot)
X8 & Older:
X8DTi, X8DTEL (limited performance, no boot support)
Common Systems:
SYS-5017C-M, SYS-1028, SYS-2029, SYS-6029
Cisco UCS Servers
M5 / M6 / M7 Generations:
C220 M5/M6/M7, C240 M5/M6/M7 (full NVMe + UEFI boot support)
M4 Generation:
C220 M4, C240 M4 (native NVMe support with firmware updates)
M3 Generation:
C220 M3, C240 M3 (storage only, no boot support)
Notes:
- Compatible primarily with C-Series rack servers
- Requires appropriate PCIe riser (x8/x16)
- Not directly supported in B-Series blades without expansion sled
Lenovo Servers
ThinkSystem V2 / V3:
SR630 V3, SR650 V3, ST650 V2 (full NVMe + boot support)
ThinkSystem Gen1:
SR630, SR650, ST550 (native NVMe boot support)
ThinkServer Series:
RD650, TD350 (storage + UEFI boot support)
System x (Legacy):
x3650 M5, x3550 M5 (storage only, no native boot)
Compatibility Notes
- Requires available PCIe x4, x8, or x16 slot
- Backward compatible with PCIe Gen4/Gen5 (runs at Gen3 speed)
- UEFI BIOS required for boot functionality
- Not suitable for blade servers without PCIe expansion support
- Requires high airflow (~300 LFM) for proper cooling
Operating System Support
- Windows: 8.1, 10, 11, Server 2012 R2+
- Linux: Kernel 3.3+ (Ubuntu, RHEL, CentOS)
- VMware ESXi 6.0+
- Hyper-V, Citrix Hypervisor
Key Deployment Notes
- Ideal for caching, virtualization, and high-speed storage tiers
- Best used in rack servers with strong airflow
- May require BIOS updates for full NVMe boot support on older systems
